Arbor A-Frame 2010/2011 snowboard

Gender/Age: Mens • Purpose: Freeride • Shape: Pin-tail • Bend: Camber • Base material: Sintered • Convex: No • Price in collection: $$$$+ • Flex in collection: soft ○○○○● stiff • Original flex index: 4

This model seems to be out of stock

On this page: Features and technologies Manufacturer's description Measurements This model in the past Also viewed	Pictures

	158 Compare waist: 249 mm	162 Compare waist: 251 mm	166 Compare waist: 253 mm	170 Compare waist: 255 mm

Features and technologies

Base	Rocket Base
Collection	The Roots Series
Construction	Mountain Stance
Core	Shaman Core, Shallow Shadow Flex
Reinforcement	Hi-Load Glassing, Carbon Torsion A-Frames
Sidecut	Standard Progressive
Sidewall	Power Rails
Top sheet	Bio-Film, Wood Power Ply

Manufacturer's description

A big-mountain gun for riders who want superior on-edge performance; lock-n-hold deeply carved lines, find powerful control in the steeps and amazing stability at speed. New Bamboo Power Rails deliver improved return.

Measurements and parameters

Size, cm	158	162	166	170
Length, mm	1580	1620	1660	1700
Effective edge, mm	1210	1246	1282	1318
Nose width, mm	294	298	301	305
Waist width, mm	249	251	253	255
Tail width, mm	292	296	299	303
Sidecut radius, mm	9000, 8100	9200, 8300	9400, 8500	9600, 8700
Stance width, mm	540	540	540	540
Setback, mm	20	20	20	20
Rider's weight, kg	57-93	61-97	64-101	68-104

This snowboard model in other seasons collections


2011/2012	2010/2011	2009/2010	2008/2009	2007/2008
